Marine Manifolds

Marine manifolds adopt vertical arrangement, high integration, and different in composition to land manifolds, such as adopting jumping line. Marine manifolds comprise mud pumps discharging manifolds, jumping lines, riser pipe manifolds, cementing manifolds, choke and kill manifolds and all its pipeline etc.

Technical Parameters

Working Pressure： 35~105MPa（５000psi~15000psi)

Nominal Diameter： 50~125mm(2"~5")

Temperature Level： -46℃~121℃（level L-U）

Working Condition： Standard, low temperature, acid (H2S)

Manufacturing Standards：SY/T5244、API 6A、NACE MR0175 etc
